S Code Bits Used Value Description
S06
Cont…..
B00000000
---↑----
0
Ch. 1 and Ch. 3 no bit overlap
1
Ch. 1 and Ch. 3 bit overlap
B00000000
----↑---
0
Ch. 1 and Ch. 4 no bit overlap
1
Ch. 1 and Ch. 4 bit overlap
B00000000
-----↑--
0
Ch. 2 and Ch. 3 no bit overlap
1
Ch. 2 and Ch. 3 bit overlap
B00000000
------↑-
0
Ch. 2 and Ch. 4 no bit overlap
1
Ch. 2 and Ch. 4 bit overlap
B00000000
-------↑
0
Ch. 3 and Ch. 4 no bit overlap
1
Ch. 3 and Ch. 4 bit overlap
S07
B00000000
----↑---
0
Bus B, Baud clock PLL not OK
1
Bus B, Baud clock PLL OK
B00000000
-----↑--
0
Bus A, Baud clock PLL not OK
1
Bus A, Baud clock PLL OK
B00000000
------↑-
0
Bus B not OK
1
Bus B OK
B00000000
-------↑
0
Bus A not OK
1
Bus A OK
S08
B00000000
--------
Undefined (Reserved for future use)
