RFL DS-562I RFL Electronics Inc.
June 14, 2007 17 (973) 334-3100
Table 9. Timeslot settings, RFL DS-562I
T1
Timeslot
SW1-1
(A4)
SW1-2
(A3)
SW1-3
(A2)
SW1-4
(A1)
SW1-5
(A0)
E1
Timeslot
1 RIGHT RIGHT RIGHT RIGHT RIGHT N/A
2 RIGHT RIGHT RIGHT RIGHT LEFT 1
3 RIGHT RIGHT RIGHT LEFT RIGHT 2
4 RIGHT RIGHT RIGHT LEFT LEFT 3
5 RIGHT RIGHT LEFT RIGHT RIGHT 4
6 RIGHT RIGHT LEFT RIGHT LEFT 5
7 RIGHT RIGHT LEFT LEFT RIGHT 6
8 RIGHT RIGHT LEFT LEFT LEFT 7
9 RIGHT LEFT RIGHT RIGHT RIGHT 8
10 RIGHT LEFT RIGHT RIGHT LEFT 9
11 RIGHT LEFT RIGHT LEFT RIGHT 10
12 RIGHT LEFT RIGHT LEFT LEFT 11
13 RIGHT LEFT LEFT RIGHT RIGHT 12
14 RIGHT LEFT LEFT RIGHT LEFT 13
15 RIGHT LEFT LEFT LEFT RIGHT 14
16 RIGHT LEFT LEFT LEFT LEFT 15
17 LEFT RIGHT RIGHT RIGHT RIGHT 16 *
18 LEFT RIGHT RIGHT RIGHT LEFT 17
19 LEFT RIGHT RIGHT LEFT RIGHT 18
20 LEFT RIGHT RIGHT LEFT LEFT 19
21 LEFT RIGHT LEFT RIGHT RIGHT 20
22 LEFT RIGHT LEFT RIGHT LEFT 21
23 LEFT RIGHT LEFT LEFT RIGHT 22
24 LEFT RIGHT LEFT LEFT LEFT 23
N/A LEFT LEFT RIGHT RIGHT RIGHT 24
N/A LEFT LEFT RIGHT RIGHT LEFT 25
N/A LEFT LEFT RIGHT LEFT RIGHT 26
N/A LEFT LEFT RIGHT LEFT LEFT 27
N/A LEFT LEFT LEFT RIGHT RIGHT 28
N/A LEFT LEFT LEFT RIGHT LEFT 29
N/A LEFT LEFT LEFT LEFT RIGHT 30
N/A LEFT LEFT LEFT LEFT LEFT 31
* Do not use timeslot 16 in an E1 system which uses CAS (channel associated signalling).
