Table 10. Transmit & Receive Address Settings, RFL DS-562I
(Used only in 56 Kbps mode)
Trans/Rcv
Address
SW2/3-1
(A5)
SW2/3-2
(A4)
SW2/3-3
(A3)
SW2/3-4
(A2)
SW2/3-5
(A1)
SW2/3-6
(A0)
0 (disabled) RIGHT RIGHT RIGHT RIGHT RIGHT RIGHT
1 RIGHT RIGHT RIGHT RIGHT RIGHT LEFT
2 RIGHT RIGHT RIGHT RIGHT LEFT RIGHT
3 RIGHT RIGHT RIGHT RIGHT LEFT LEFT
4 RIGHT RIGHT RIGHT LEFT RIGHT RIGHT
5 RIGHT RIGHT RIGHT LEFT RIGHT LEFT
6 RIGHT RIGHT RIGHT LEFT LEFT RIGHT
7 RIGHT RIGHT RIGHT LEFT LEFT LEFT
8 RIGHT RIGHT LEFT RIGHT RIGHT RIGHT
9 RIGHT RIGHT LEFT RIGHT RIGHT LEFT
10 RIGHT RIGHT LEFT RIGHT LEFT RIGHT
11 RIGHT RIGHT LEFT RIGHT LEFT LEFT
12 RIGHT RIGHT LEFT LEFT RIGHT RIGHT
13 RIGHT RIGHT LEFT LEFT RIGHT LEFT
14 RIGHT RIGHT LEFT LEFT LEFT RIGHT
15 RIGHT RIGHT LEFT LEFT LEFT LEFT
16 RIGHT LEFT RIGHT RIGHT RIGHT RIGHT
17 RIGHT LEFT RIGHT RIGHT RIGHT LEFT
18 RIGHT LEFT RIGHT RIGHT LEFT RIGHT
19 RIGHT LEFT RIGHT RIGHT LEFT LEFT
20 RIGHT LEFT RIGHT LEFT RIGHT RIGHT
21 RIGHT LEFT RIGHT LEFT RIGHT LEFT
22 RIGHT LEFT RIGHT LEFT LEFT RIGHT
23 RIGHT LEFT RIGHT LEFT LEFT LEFT
24 RIGHT LEFT LEFT RIGHT RIGHT RIGHT
25 RIGHT LEFT LEFT RIGHT RIGHT LEFT
26 RIGHT LEFT LEFT RIGHT LEFT RIGHT
27 RIGHT LEFT LEFT RIGHT LEFT LEFT
28 RIGHT LEFT LEFT LEFT RIGHT RIGHT
29 RIGHT LEFT LEFT LEFT RIGHT LEFT
30 RIGHT LEFT LEFT LEFT LEFT RIGHT
31 RIGHT LEFT LEFT LEFT LEFT LEFT
32 LEFT RIGHT RIGHT RIGHT RIGHT RIGHT
33 LEFT RIGHT RIGHT RIGHT RIGHT LEFT
34 LEFT RIGHT RIGHT RIGHT LEFT LEFT
35 LEFT RIGHT RIGHT RIGHT LEFT LEFT
36 LEFT RIGHT RIGHT LEFT RIGHT RIGHT
37 LEFT RIGHT RIGHT LEFT RIGHT LEFT
38 LEFT RIGHT RIGHT LEFT LEFT RIGHT
39 LEFT RIGHT RIGHT LEFT LEFT LEFT
40 LEFT RIGHT LEFT RIGHT RIGHT RIGHT
41 LEFT RIGHT LEFT RIGHT RIGHT LEFT
42 LEFT RIGHT LEFT RIGHT LEFT RIGHT
43 LEFT RIGHT LEFT RIGHT LEFT LEFT
44 LEFT RIGHT LEFT LEFT RIGHT RIGHT
45 LEFT RIGHT LEFT LEFT RIGHT LEFT
