RFL DS-562I RFL Electronics Inc.
June 14, 2007 19 (973) 334-3100
Table 10. (continued) Transmit & Receive Address Settings, RFL DS-562I
(Used only in 56 Kbps mode)
Trans/Rcv
Address
SW2/3-1
(A5)
SW2/3-2
(A4)
SW2/3-3
(A3)
SW2/3-4
(A2)
SW2/3-5
(A1)
SW2/3-6
(A0)
46 LEFT RIGHT LEFT LEFT LEFT RIGHT
47 LEFT RIGHT LEFT LEFT LEFT LEFT
48 LEFT LEFT RIGHT RIGHT RIGHT RIGHT
49 LEFT LEFT RIGHT RIGHT RIGHT LEFT
50 LEFT LEFT RIGHT RIGHT LEFT RIGHT
51 LEFT LEFT RIGHT RIGHT LEFT LEFT
52 LEFT LEFT RIGHT LEFT RIGHT RIGHT
53 LEFT LEFT RIGHT LEFT RIGHT LEFT
54 LEFT LEFT RIGHT LEFT LEFT RIGHT
55 LEFT LEFT RIGHT LEFT LEFT LEFT
56 LEFT LEFT LEFT RIGHT RIGHT RIGHT
57 LEFT LEFT LEFT RIGHT RIGHT LEFT
58 LEFT LEFT LEFT RIGHT LEFT RIGHT
59 LEFT LEFT LEFT RIGHT LEFT LEFT
60 LEFT LEFT LEFT LEFT RIGHT RIGHT
61 LEFT LEFT LEFT LEFT RIGHT LEFT
62 LEFT LEFT LEFT LEFT LEFT RIGHT
63 LEFT LEFT LEFT LEFT LEFT LEFT
