Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
RFL DS-562I RFL Electronics Inc.
June 14, 2007 34 (973)
334-3100
Table 15. Remote Configuration Settings (“P” codes)
P Code Bits Used Value Description
SRVC ... ON Turns service on (module enabled).
OFF Turns service off (module disabled).
P01 B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑
T1: 1 to 24
E1: 1 to 31
Selects the receive and transmit timeslot. Used in 56K mode
onl
y. *
P02 B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑
0 to 63 Sets the transmit address (See Table 8). Used in 56K mode
only.
*
P03 B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑
0 to 63 Sets the receive address (See Table 8)
P04 B 0 0 0 0 0 0 0 0 0 Octet timing OFF
↑ 1 Octet timing ON
B 0 0 0 0 0 0 0 0 0 Normal receive clock polarity
↑ 1 Inverted receive clock polarity
B 0 0 0 0 0 0 0 0 0 Normal transmit clock polarity
↑ 1 Inverted transmit clock polarity
B 0 0 0 0 0 0 0 0 0 Squelch OFF
↑ 1 Squelch output to user equipment upon loss of valid address
B 0 0 0 0 0 0 0 0
↑
0 No remotely commanded equipment loopback (may be
overridden at board)
1 Remotely commanded equipment loopback
B 0 0 0 0 0 0 0 0
↑
0 No remotely commanded payload loopback (may be
overridden at board)
1 Remotely commanded payload loopback
B 0 0 0 0 0 0 0 0 0 64 Kbps data rate
↑ 1 56 Kbps data rate
B 0 0 0 0 0 0 0 0 Transmit on bus B
↑ 1 Transmit on bus A
P05 B 0 0 0 0 0 0 0 0 0 T1 carrier
↑ 1 E1 carrier
B 0 0 0 0 0 0 0 0 0 No handshaking delay
↑ 1 8 microsecond handshaking delay (approx.)
B 0 0 0 0 0 0 0 0 0 Normal
↑ 1 Inverted data
* It is recommended that the TX and RX addresses are both set to a value other than 0 if the addressing function is being used.
