Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
RFL DS-562I RFL Electronics Inc.
June 14, 2007 35 (973) 334-3100
“S” CODES
“S” codes appear in response to a “STATUS?” query. There are four “S” codes for the RFL DS-
562I. Like the “P” codes, each “S” code is a number displayed in both decimal and binary form.
A typical response to a “STATUS?” query looks like this:
*OK
CHANNEL CARD 3, TYPE 119
S01 = 0 (B00000000)
S02 = 57 (B00111001)
S03 = 0 (B00000000) (not currently used)
S04 = 0 (B00000000) (not currently used)
These codes provide information on the status of several conditions on the RFL DS-562I module.
Table 16 lists the meaning of all “S” codes for the RFL DS-562I module.
Table 16. Remote status messages (“S” codes)
Code Bits Used Value Description
S01 B 00000000 0 MA-406IA (RS-449), DCE mode / or MA-620 installed
↑↑↑↑↑↑↑↑
1 MA-406IA installed (RS-449) or MA-410I (X.21), DTE mode.
2 MA-409IA installed (V.35), DCE mode.
3 MA-409IA installed (V.35), DTE mode.
4 MA-407I installed (G.703 contradirectional).
5 MA-408I installed (G.703 codirectional).
6 MA-410I installed (X.21), DCE mode.
7 MA-600 installed (short haul fiber)
S02 B 00000000 0 Service off (module disabled).
↑↑↑↑↑↑↑↑
1 Service on (module enabled).
B 00000000
↑↑↑↑
↑↑↑↑
0 RX address is disabled, or RX address is enabled and the DS-562I is not
receiving a properly addressed signal. Used in 56K m
ode only.
1 RX address is enabled, and the DS-562I is receiving a properly addressed
signal. Used in 56K mode only.
B 00000000 0 The transmit address is disabled. Used in 56K mode only.
↑↑↑↑↑↑↑↑
1 The transmit address is enabled. Used in 56K mode only.
B 00000000 0 The equipment loopback is disabled.
↑↑↑↑↑↑↑↑
1 The equipment loopback is enabled.
B 00000000 0 The payload loopback is disabled.
↑↑↑↑↑↑↑↑
1 The payload loopback is enabled.
B 00000000 0 The DS-562I is not receiving data from the remote equipment.
↑↑↑↑↑↑↑↑
1 The DS-562I is receiving data from the remote equipment.
B 00000000 0 The DS-562I is not transmitting data from the remote equipment.
↑↑↑↑↑↑↑↑
1 The DS-562I is transmitting data from the remote equipment.
SO3 Not currently used
SO4 Not currently used
