DS-562NC INSTALLATION INSTRUCTIONS
Before the DS-562NC module can be placed in service, it must be installed in a multiplexer shelf.
Installation involves determining the module slot in the Main Shelf or Expansion Shelf where the
module will be installed, inserting an I/O adapter module into the rear of the shelf behind the module
slot, connecting all signal wiring to the I/O adapter module, checking the settings of all switches and
jumpers, and inserting the module into the front of the shelf.
NOTE
Power supply and time slot considerations may affect the installation of RFL DS-562NC
modules into an existing multiplexer shelf. Refer to the portions of your multiplexer operation
manual covering “Channel Module Configuration Guidelines” and “Adding More Channel
Modules To Existing Systems” for more information.
The following instructions are provided for installing RFL DS-562NC modules into existing
systems. If the module was included as part of a system, installation was done at the factory,
otherwise, proceed as follows:
1. Carefully inspect the RFL DS-562NC and its I/O adapter module for shipping damage.
If you suspect damage to the module or its Module Adapter, immediately contact
RFL’s Customer Service Department at the number shown at the bottom of this page.
2. Determine which module slot in the Main Shelf or Expansion Shelf the RFL DS-562NC
will be installed in.
The RFL DS-562NC module occupies one module slot in the Main Shelf or
Expansion Shelf. Refer to the “as supplied” drawings furnished with the
equipment for more information.
3. Determine which I/O Adapter Module will be used to make connections to the RFL DS-562NC
module.
Each RFL DS-562NC module installed in an IMUX 2000 multiplexer requires an
I/O Adapter Module. The I/O Adapter Module provides the appropriate
connections for the desired interface.
There are eleven Module Adapters for the RFL DS-562NC:
Module
Adapter
Part Number Interface Type Socket Figure
MA-406IA
MA-406IB
MA-407I
MA-408I
MA-409IA
MA-410I
MA-600
MA-620
MA-621
MA-427
MA-428
9547-16331
9547-16632
9547-1750
9547-1755
9547-17271
9547-1760
9547-600
107245(multimode)
107245-1(singlemode)
9547-22361
9547-22362
RS-449
RS-530
G.703 contra-di
rect
ional
G.703 co-directional
V.35
X.21
Optical fiber
C
37.94
ANSI SHF
C37.94
ANSI SHF
IEEE 802.3 LAN
IEEE 802.3 LAN
37 pin D-subminiature (DB-37S)
25 pin D-subminiature (DB-25S)
25 pin D-subminiature (DB-25S)
25 pin D-subminiature (DB-25S)
37 pin D-subminiature (DB-37S)
15 pin D-subminiature (DB-15S)
Type ST
Type ST
Type ST
RJ-45
RJ-45
1
2
3
4
5
6
8
10
10
12
14
Make sure the I/O Module Adapter you are installing is correct for the desired
application.
