Verifying LAN-to-LAN Operation
Once you have completed the installation, verify that the MA-427 LAN Bridge is operating properly
by checking LAN-to-LAN operation with your network administrator. You can also verify the
operation of the MA-427 by checking its LEDs. Table 18 describes the LEDs and their state under
normal operating conditions when connected to a functioning LAN.
Table 18. MA-427 LAN Bridge LEDs
LED Color State Function Normal State
WAN TX/RX Yellow On Indicates transmission of data to or
receiving data from the WAN
This LED will flash on and
off when connected to a
functioning WAN
Off Indicates no transmission of data to or
receiving data from the WAN
LAN TX/RX Yellow On Indicates transmission of data to or
receiving data from the LAN
This LED will flash on and
off when connected to a
functioning LAN
Off Indicates no transmission of data to or
receiving data from the LAN
LINK Green On Indicates connection to LAN This LED should always be
on when connected to a
functioning LAN
Off
Indicates no connection to LAN
Troubleshooting
Use the table below to troubleshoot any problems you encounter during installation or operation of the
MA-427 LAN Bridge.
Table 19. Troubleshooting Problems and Solutions for the MA-427 LAN Bridge
Problem Probable Cause Solution
No LAN connection Remove and reconnect the RJ-45 cable connected to the
MA-427 port.
Wrong cable for device
connection
Check that the proper cable is being used. Use UTP RJ-45
for hub or Ethernet switch. Use UTP RJ-45 with crossover for
PC or NIC. See Table 17.
Problem with LAN See your network administrator
LINK LED is not on
T1/E1 link is not
working
Contact your T1/E1 service provider
No LAN connection Verify that the LINK LED is on. If it is not, see “LINK LED is
not on” above
Incompatible switch
settings
Verify that the COMPR switch settings are the same at both
ends of the network.
Verify that the FILTER switch settings are the same on both
ends of the network.
Verify that the WMODE and MODE 0-4 switches are set to
their defaults. See Table 16.
Problem with LAN See your network administrator
No LAN-to-LAN
communication
(data is not being
sent or received)
Synchronous data link
is not working
Check the operation of the DS-562NC using the DS-562NC
troubleshooting procedure on page 50.
WAN TX/RX LED
and LAN TX/RX
LED are always on
MODE 0 switch is in
the DOWN position
Set the MODE 0 switch to the UP position. See Figure 12 for
the switch location.
