Table 31. Remote Configuration Settings (“P” codes)
P Code Bits Used Value Description
0 Turns service off (module disabled) SRVC B 0 0 0 0 0 0 0 0
↑
1 Turns service on (module enabled)
0 Transmit on bus B B 0 0 0 0 0 0 0 0
↑
1 Transmit on bus A
0 CAS (channel associated signaling) disabled for E1 B 0 0 0 0 0 0 0 0
↑
1 CAS enabled for E1
P01
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑
T1: 1 to 24
E1: 1 to 31
Timeslot selection (binary)*
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑
T1: 1 to 24
E1: 1 to 31
Number of timeslots used (N-baud)**
0 Selects 64Kbps mode (N = 1 to 24/31) B 0 0 0 0 0 0 0 0
↑
1 Selects 56Kbps mode (N=1 only)
0 No remotely commanded payload loopback (may be
overridden at board by SW12)
B 0 0 0 0 0 0 0 0
↑
1 Remotely commanded payload loopback
0 No remotely commanded equipment loopback (may be
overridden at board by SW12)
P02
B 0 0 0 0 0 0 0 0
↑
1 Remotely commanded equipment loopback
P03 B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑
0 to 63 Sets the transmit address (56Kbps only
, 0=disabled).
See table 11.
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑
0 to 63 Sets the receive address (56Kbps only
, 0=disabled).
See table 11.
0 Squelch OFF
P04
B 0 0 0 0 0 0 0 0
↑
1 Squelch output to user equipment upon loss of valid address
(56Kbps only
)
0 Octet timing OFF (G.703 only) P05 B 0 0 0 0 0 0 0 0
↑
1 Octet timing ON (G.703 only)
0 No handshaking delay B 0 0 0 0 0 0 0 0
↑
1 8 microseconds handshaking delay (approx.)
0 Normal receive clock polarity B 0 0 0 0 0 0 0 0
↑
1 Inverted receive clock polarity
0 Normal receive data polarity B 0 0 0 0 0 0 0 0
↑
1 Inverted receive data polarity
0 Normal transmit clock polarity B 0 0 0 0 0 0 0 0
↑
1 Inverted transmit clock polarity
