Table 31. Remote Configuration Settings (“P” codes) Continued…..
P Code Bits Used Value Description
0 Normal transmit data polarity P05 B 0 0 0 0 0 0 0 0
↑
1 Inverted transmit data polarity
B 0 0 0 0 0 0 0 0
↑ ↑
Bit1 Bit0
0 0
Selects RS-449/X.21/V.35 (standard mode)
B 0 0 0 0 0 0 0 0
↑ ↑
Bit1 Bit0
0 1
Selects MA-620 – Short-Haul Fiber (C.37.94)
P06
B 0 0 0 0 0 0 0 0
↑ ↑
Bit1 Bit0
1 0
Selects MA-427/428 – Ethernet
P07 Currently used for
test-point control
TP7
P08 Currently used for
test-point control
TP8
P09 Currently used for
test-
oint control
TP9
P010 Currently used for
test-point control
TP10
* It i
s recommended that the TX and RX addresses are both set to
a value other than 0 if the addressing function is
being used.
**
Subject to limits due to the starting timeslot number and CAS (for E1).
