“S” CODES
“S” codes appear in response to a “STATUS?” query. There are ten “S” codes for the RFL DS-
562NC. Like the “P” codes, each “S” code is a number displayed in both decimal and binary form.
A typical response to a “STATUS?” query looks like this:
*OK
CHANNEL CARD 3, TYPE 116
S01 = 0 (B00000000)
S02 = 199 (B11000111)
S03 = 0 (B00000000)
S04 = 65 (B01000001)
S05 = 127 (B01111111)
S06 = 0 (B00000000)
S07 = 0 (B00000000)
S08 = 0 (B00000000)
S09 = 0 (B00000001)
S10 = 0 (B00000001);
These codes provide information on the status of several conditions on the RFL DS-562NC
module. Table 21 lists the meaning of all “S” codes for the RFL DS-562NC module.
Table 32. Remote status messages (“S” codes)
S Code Bits Used Value Description
0 MA-406IA (RS-449 DCE) installed
1 MA-406IA, MA-410 (RS-449/X.21 DTE) installed
2 MA-409IA (V.35 DCE) installed
3 MA-409IA (V.35 DTE) installed
4 MA-407I (G.703 contra directional) installed
5 MA-408I (G.703 co directional) installed
6 MA-410 (X.21 DCE) installed
7 MA-600 RFL Short Haul Fiber installed
8 MA-620 (C37.94 Short Haul Fiber) installed
9 MA-427/428 (Ethernet Module) installed
S01
(I/O Type ID)
Binary value
255 Invalid 1/O Type or setting
