NOTE
Unlike other RFL IMUX Modules, Module Service for the OCUDP Module is not controlled
by parameter SRVC = ON/OFF. The value of parameter SRVC returned in response a
configuration inquiry has no meaning for the OCUDP Module.
Module Service for the OCUDP Module is controlled by bit 5 of [7:0] of configuration
parameter P4.
The RFL OCUDP Module may be configured as follows:
User command:
<MULTIPLEXER ADDRESS>:<CARD ADDRESS>:SET:<PARAMETER>=<VALUE>;
The value may be in decimal format or in binary (binary value preceded by B).
For example, Module Service for the OCUDP with Card Address 3, located in Multiplexer Shelf 2,
may be set as follows:
2:C3:SET:P4=B00110110;
Note that the complete parameter must be set; in this particular example, parameter P4 configured
Module Service to be ON and Receive Time Slot = 10.
The RFL OCUDP Module may be interrogated about its status, as follows.
User command:
<MULTIPLEXER ADDRESS>:<CARD ADDRESS>:STATUS?:;
Typical OCUDP Module response (actual values depend on current status):
*OK
FROM NET ADDRESS 2
CHANNEL CARD 3, TYPE 124
S01 = 67 (B01000011)
S02 = 47 … (etc.)
…
For convenience, status values are returned both in decimal and binary format.
