Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
RFL OCUDP RFL Electronics Inc.
July 15, 2010 17 (973)
334-3100
Table 5. Remote configuration settings (“P” codes) for OCUDP module
P Code Bit positions Value
(1)
Description
P1 B 0 0 0 0 0 0 0 0 . . . Spare
P2 B 0 0 0 0 0 0 0 0
-
- - - ↑ ↑ ↑ ↑
BAUD RATE
0000 to 1111
1000 = 56.0 kbps user rate
1111 = 64.0 kbps user rate
Other values invalid
B 0 0 0 0 0 0 0 0
- - - ↑ - - - -
SW56
1 Not used
0 Disable switch 56 operation (must be set to this value)
B 0 0 0 0 0 0 0 0
- - ↑ - - - - -
ZERO CODE SUPPRESSION
1 Enable zero code suppression
0 Disable zero code suppression
B 0 0 0 0 0 0 0 0
-
↑ - - - - - -
AB SIGNALING
1 Enable AB signaling
0 Disable AB signaling
B 0 0 0 0 0 0 0 0
↑
- - - - - - -
. . . Not used
P3 B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑
RECEIVE TIME SLOT
00000 to
11111
Sets receive time slot in accordance with Table 3, with
“OFF” equivale
nt to 1 and “ON” equivalent to 0.
B 0 0 0 0 0 0 0 0
- - ↑ - - - - -
A/B DIRECTION
1 Transmit on A, receive on B
0 Transmit on B, receive on A
B 0 0 0 0 0 0 0 0
- ↑ - - - - - -
QUALITY MONITOR
. . .
Not used
1 Loss of sealing current causes alert
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
SEALING CURRENT
ALERT
0 Loss of sealing current does not cause alert
1. These are the only legal values for setting the parameters. Setting any parameter to a value outside its
specified range will produce an unpredictable result.
