RFL OCUDP RFL Electronics Inc.
July 15, 2010 18 (973) 334-3100
Table 5. - continued. Remote configuration settings (“P” codes) for OCUDP module
P Code Bit positions Value
(1)
Description
B 0 0 0 0 0 0 0 0
- - - ↑ ↑ ↑ ↑ ↑
TRANSMIT TIMESLOT
00000 to
11111
Sets transmit timeslot in accordance with Table 3
With “OFF” equivalent to 1 and “ON” equivalent to 0
1 Module service enabled
P4
B 0 0 0 0 0 0 0 0
- - ↑ - - - - -
MODULE SERVICE ENABLE
0 Module service disabled
B 0 0 0 0 0 0 0 0
↑ ↑ - - - - - -
. . . Not Used
P5 B 0 0 0 0 0 0 0 0
- - - - - - - ↑
DIGITAL LOOPBACK
1
Loopback enabled
0 Loopback disabled
B 0 0 0 0 0 0 0 0
- - - - - - ↑ -
LATCHING LOOPBACK
FUNCTIONALITY
1 Latching loopback functionality for DSU and channel,
enable (this perm
its reception of inline control codes)
0 Latching loopback functionality for DSU and channel,
disable
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
RESET LATCHED STATUS
1 0 to 1 transition resets latching status, Contained in
St
at
us Bytes S4 through S7
0
B 0 0 0 0 0 0 0 0
- ↑ ↑ ↑ ↑ ↑ - -
. . . Not used
P6 B 0 0 0 0 0 0 0 0
. . . Spare
Notes:
For time slot selection, the setting of switches shown in Table 3.are equivalent to
Remote Control Settings as follows:
TX Slot: Local Control SW2 – Positions 5 through 1
Remote Control P4 – Bits 4 through 0.
RX Slot: Local Control SW3 – Positions 5 through 1
Remote Control P3 – Bits 4 through 0.
Example: Time slot 10:
SW2/3 = X X X OFF OFF OFF OFF ON
P4/3 = X X X 1 0 1 1 0
