Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
RFL OCUDP RFL Electronics Inc.
July 15, 2010 23 (973) 334-3100
Table 6. – continued, Remote status messages (“S” codes) for OCUDP module
S CODE Position Value Description
S6** B 0 0 0 0 0 0 0 0
- - - - - - - ↑
TRANSMITTING IDLE
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
B 0 0 0 0 0 0 0 0
- - - - - - ↑ -
TRANSMITTING
LOOPBACK
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
B 0 0 0 0 0 0 0 0
- - - - - ↑ - -
TRANSMITTING
ABNORMAL STATION
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
S7
B 0 0 0 0 0 0 0 0
. . . Spare
** S6 Remote Status Message from data port side. Not used in 64 kbps mode.
Note:
Status bits in S6 latch events occurred since the last reset of the Latched Status. To refresh S6,
toggle P5 – Bit 7 (Reset Latched Status) from 0 to 1
Table 7. LS Loop Length Bits LL3-LL0
Approximate line loss in dB/Loop length in km (24 AWG, no bridged taps) *
User
Rate
Kbps
0111 1000 1001 1010 1011 1100 1101 1110 1111
56.0 50.5/8.5 44.4/7.5 38.4/6.4 32.3/5.3 26.0/4.2 19.7/3.2 13.6/2.1 7.3/1.1 0.0/0.0
64.0 50.7/8.0 45.0/7.0 38.8/6.0 32.5/5.0 26.3/4.0 20.0/3.0 14.0/2.0 7.4/1.0 0.0/0.0
* Based on received signal strength/filter selection, assuming far-end pulse transm
ission compliant with AT&T Pub 62310
or T1E1/90-051. See LEVEL ONE LXT400 data sheet, Revision 3.2 for more information.
