Table 6. – continued, Remote status messages (“S” codes) for OCUDP module
S CODE Position Value Description
S5* B 0 0 0 0 0 0 0 0
- - - - - - - ↑
RELEASE CODE
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
B 0 0 0 0 0 0 0 0
- - - - - - ↑ -
BLOCK CODE
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
B 0 0 0 0 0 0 0 0
- - - - - ↑ - -
TRANSIT IN PROGRESS
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
B 0 0 0 0 0 0 0 0
- - - - ↑ - - -
FAR-END VOICE
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
B 0 0 0 0 0 0 0 0
- - - ↑ - - - -
LOOPBACK ENABLE
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
B 0 0 0 0 0 0 0 0
- - ↑ - - - - -
MULTIPOINT UNIT
ALERT
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
B 0 0 0 0 0 0 0 0
- ↑ - - - - - -
TEST ALERT
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
* S5 Remote Status Message from T1 side. Not used in 64 kbps mode.
Note:
Status bits in S5 latch events occurred since the last reset of the Latched Status. To refresh
S5, toggle P5 – Bit 7 (Reset Latched Status) from 0 to 1.
