Table 6. – continued, Remote status messages (“S” codes) for OCUDP module
S CODE Position Value Description
S4* B 0 0 0 0 0 0 0 0
- - - - - - - ↑
TEST CODE
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
B 0 0 0 0 0 0 0 0
- - - - - - ↑ -
UNASSIGNED MUX
CHANNEL
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
B 0 0 0 0 0 0 0 0
- - - - - ↑ - -
MUX-OUT-OF-SYNC
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
B 0 0 0 0 0 0 0 0
- - - - ↑ - - -
ABNORMAL STATION
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
B 0 0 0 0 0 0 0 0
- - - ↑ - - - -
OCU LOOPBACK
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
B 0 0 0 0 0 0 0 0
- - ↑ - - - - -
DSU LOOPBACK
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
B 0 0 0 0 0 0 0 0
- ↑ - - - - - -
CHANNEL LOOPBACK
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
RECEIVING IDLE CODE
1 Code detected in data stream.
0 Code not detected in data stream since last reset.
* S4 Remote Status Message from T1 side. Not used in 64 kbps mode.
Note:
Status bits in S4 latch events occurred since the last reset of the Latched Status. To refresh
S4, toggle P5 – Bit 7 (Reset Latched Status) from 0 to 1.
