Because RFL and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specications without notice.
RFL VF-5C RFL Electronics Inc.
October 8, 2012 24 (973)
334-3100
21. Set the position of SW7-1 to SW7-7 to select the Channel 1 RX Address. The settings for SW7 are the
same as SW6.
22. Set the position of SW10-1 to SW10-7 to select the Channel 2 TX Address. The settings for SW10 are
the same as SW6.
23. Set the position of SW11-1 to SW11-7 to select the Channel 2 RX Address. The settings for SW11 are
the same as SW6.
24. If you plan to operate the RFL VF-5C module under local control, first perform steps 1 through
23, then perform the following steps; otherwise go to step 25.
a. Set to local control by placing DIP switch SW3-9 in the UP position.
b. Turn service on by placing DIP switch SW3-10 in the UP position.
c. Slide the module into the selected slot until it is firmly seated and the module front panel is flush
with the top and bottom of the shelf.
d. Go to step 26.
25. If you plan to operate the RFL VF-5CB module under remote control, first perform steps 1 through 26,
then perform the following steps:
a. Set to local control by placing DIP switch SW3-9 in the UP position.
b. Turn service off by placing DIP switch SW3-10 in the DOWN position.
c. Slide the module into the selected slot until it is firmly seated and the module front panel is flush
with the top and bottom of the shelf.
d. Wait 15 seconds for the module’s parameter settings to be loaded into the shelf Common
Module.
e. Pull the module out of the shelf, and place DIP switch SW3-9 in the DOWN position.
Do not move SW3-10.
f. Slide the module back into the shelf.
g. Verify the module configuration through remote control by using NMS.
h. Turn service on through remote control by using NMS.
The operating parameters of the RFL VF-5C can now be changed by remote
control. See page 31 of this Instruction Data Sheet for more information on remote
control using NMS.
i. Go to step 26.
26. On the Module Record Card (located to the right of the shelf) record the channel bank type, time slot,
and any other pertinent information.
The RFL VF-5C is now installed. If your multiplexer is set up for remote access and control, you can now change
the operating parameters of the module by using NMS. For more information on remote access and control,
consult your multiplexer operation manual.
