RFL VF-6I RFL Electronics Inc.
December 15, 2011 13 (973) 334-3100
Table 2. SCB address settings, RFL VF-6I Four Wire Orderwire Voice Frequency Module
Module
Address
SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6
1
DOWN DOWN DOWN DOWN DOWN UP
2
DOWN DOWN DOWN DOWN UP DOWN
3
DOWN DOWN DOWN DOWN UP UP
4
DOWN DOWN DOWN UP DOWN DOWN
5
DOWN DOWN DOWN UP DOWN UP
6
DOWN DOWN DOWN UP UP DOWN
7
DOWN DOWN DOWN UP UP UP
8
DOWN DOWN UP DOWN DOWN DOWN
9
DOWN DOWN UP DOWN DOWN UP
10
DOWN DOWN UP DOWN UP DOWN
11
DOWN DOWN UP DOWN UP UP
12
DOWN DOWN UP UP DOWN DOWN
13
DOWN DOWN UP UP DOWN UP
14
DOWN DOWN UP UP UP DOWN
15
DOWN DOWN UP UP UP UP
16
DOWN UP DOWN DOWN DOWN DOWN
17
DOWN UP DOWN DOWN DOWN UP
18
DOWN UP DOWN DOWN UP DOWN
19
DOWN UP DOWN DOWN UP UP
20
DOWN UP DOWN UP DOWN DOWN
21
DOWN UP DOWN UP DOWN UP
22
DOWN UP DOWN UP UP DOWN
23
DOWN UP DOWN UP UP UP
24
DOWN UP UP DOWN DOWN DOWN
25
DOWN UP UP DOWN DOWN UP
26
DOWN UP UP DOWN UP DOWN
27
DOWN UP UP DOWN UP UP
28
DOWN UP UP UP DOWN DOWN
29
DOWN UP UP UP DOWN UP
30
DOWN UP UP UP UP DOWN
31
DOWN UP UP UP UP UP
32
UP DOWN DOWN DOWN DOWN DOWN
33
UP DOWN DOWN DOWN DOWN UP
34
UP DOWN DOWN DOWN UP DOWN
35
UP DOWN DOWN DOWN UP UP
36
UP DOWN DOWN UP DOWN DOWN
