Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and speciﬁcations without notice.

RFL VF-6I RFL Electronics Inc.

December 15, 2011 26 (973) 334-3100

Table 7. Time slot selection by remote access

Time Slot

P1-5*

P1-4*

P1-3*

P1-2*

P1-1*

1 0 0 0 0 1

2 0 0 0 1 0

3 0 0 0 1 1

4 0 0 1 0 0

5 0 0 1 0 1

6 0 0 1 1 0

7 0 0 1 1 1

8 0 1 0 0 0

9 0 1 0 0 1

10 0 1 0 1 0

11 0 1 0 1 1

12 0 1 1 0 0

13 0 1 1 0 1

14 0 1 1 1 0

15 0 1 1 1 1

16** 1 0 0 0 0

17 1 0 0 0 1

18 1 0 0 1 0

19 1 0 0 1 1

20 1 0 1 0 0

21 1 0 1 0 1

22 1 0 1 1 0

23 1 0 1 1 1

24 1 1 0 0 0

25 1 1 0 0 1

26 1 1 0 1 0

27 1 1 0 1 1

28 1 1 1 0 0

29 1 1 1 0 1

30 1 1 1 1 0

31 1 1 1 1 1

* These positions represent the five least significant digits of P1, as shown in Table 5.

** Not valid if signaling is enabled in E1. Time Slot 16 is reserved for CAS.
