RFL VF-15C RFL Electronics Inc.
August 7, 2012 12 (973) 334-3100
Table 3. Tx and Rx level settings, RFL VF-15C module (Ensure SW9-7 is in the UP position)
Physical Switch Settings SW1 thru SW4 Tx Input and
Rx output
Level
(dBm)
(1)
P-Codes
3,4,5,6
(Decimal)
Switch
Settings
VNMS
Settings
(dB)
2 3 4 5 6 7 8
(2)
-26 116 58 26 U U U D U D D
-25 114 57 25 U U U D D U D
-24 112 56 24 U U U D D D D
-23 110 55 23 U U D U U U D
-22 108 54 22 U U D U U D D
-21 106 53 21 U U D U D U D
-20 104 52 20 U U D U D D D
-19 102 51 19 U U D D U U D
-18 100 50 18 U U D D U D D
-17 98 49 17 U U D D D U D
-16 96 48 16 U U D D D D D
-15 94 47 15 U D U U U U D
-14 92 46 14 U D U U U D D
-13 90 45 13 U D U U D U D
-12 88 44 12 U D U U D D D
-11 86 43 11 U D U D U U D
-10 84 42 10 U D U D U D D
-9 82 41 9 U D U D D U D
-8 80 40 8 U D U D D D D
-7 78 39 7 U D D U U U D
-6 76 38 6 U D D U U D D
-5 74 37 5 U D D U D U D
-4 72 36 4 U D D U D D D
-3 70 35 3 U D D D U U D
-2 68 34 2 U D D D U D D
-1 66 33 1 U D D D D U D
0
(3)
64 32 0 U D D D D D D
Default
1 62 31 -1 D U U U U U D
2 60 30 -2 D U U U U D D
3 58 29 -3 D U U U D U D
4 56 28 -4 D U U U D D D
5 54 27 -5 D U U D U U D
6 52 26 -6 D U U D U D D
7 50 25 -7 D U U D D U D
8 48 24 -8 D U U D D D D
9 46 23 -9 D U D U U U D
10 44 22 -10 D U D U U D D
11 42 21 -11 D U D U D U D
12 40 20 -12 D U D U D D D
13 38 19 -13 D U D D U U D
14 36 18 -14 D U D D U D D
15 34 17 -15 D U D D D U D
16 32 16 -16 D U D D D D D
17 30 15 -17 D D U U U U D
18 28 14 -18 D D U U U D D
19 26 13 -19 D D U U D U D
20 24 12 -20 D D U U D D D
21 22 11 -21 D D U D U U D
22 20 10 -22 D D U D U D D
23 18 9 -23 D D U D D U D
24 16 8 -24 D D U D D D D
25 14 7 -25 D D D U U U D
26 12 6 -26 D D D U U D D
See notes for Table 3 on top of next page.
