Notes for Table 3:
1. The maximum analog level for transmit and receive is 0dBm. The TX Input Level may be increased to a value greater
t
han 0dBm to provide additional offset attenuation. The RX Input Level may be increased to a value greater than
0dBm to provide additional offset gain.
2. Note: 0.5 dB increments can also be used by SW1, 2, 3 and 4.
3. Factory default of 0dB.
Table 4. Time Slot Select for RFL VF-15C module.
Switch
Code Channel 1 Channel 2 Channel 1 Channel 2
(Decimal) 1 2 3 4 5 Time Slot Time Slot Time Slot Time Slot
0 D D D D D * * * *
1 D D D D U 1 2 1 2
2 D D D U D 2 3 2 3
3 D D D U U 3 4 3 4
4 D D U D D 4 5 4 5
5 D D U D U 5 6 5 6
6 D D U U D 6 7 6 7
7 D D U U U 7 8 7 8
8 D U D D D 8 9 8 9
9 D U D D U 9 10 9 10
10 D U D U D 10 11 10 11
11 D U D U U 11 12 11 12
12 D U U D D 12 13 12 13
13 D U U D U 13 14 13 14
14 D U U U D 14 15 14 15
15 D U U U U 15 16 15 17
16 U D D D D 16 17 * *
17 U D D D U 17 18 17 18
18 U D D U D 18 19 18 19
19 U D D U U 19 20 19 20
20 U D U D D 20 21 20 21
21 U D U D U 21 22 21 22
22 U D U U D 22 23 22 23
23 U D U U U 23 24 23 24
24 U U D D D 24 N/A 24 25
25 U U D D U * * 25 26
26 U U D U D * * 26 27
27 U U D U U * * 27 28
28 U U U D D * * 28 29
29 U U U D U * * 29 30
30 U U U U D * * 30 31
31 U U U U U * * 31 N/A
T1 E1
Physical Switch Settings
SW10-
Notes: * This setting is not allowed . Setting switches to this code will cause the module’s service to be disabled.
D = down, U = up.
RFL VF-15C RFL Electronics Inc.
August
7, 2012 13 (973) 334-3100
