RFL VF-16B RFL Electronics Inc.
January
17, 2007 9 (973) 334-3100
MA-303
1
2
3 RING
4 TIP
5
6
Figure 3. MA-303 Module Adapter, used with all RFL VF-16B station end modules. The MA-304 Module Adapter
is similar in appearance.
Figure 4. MA-303B Module Adapter, used with all RFL VF-16B station end modules. The MA-304B Module
Adapter is similar in appearance.
PIN 3 = RING
PIN 4 = TIP
PINS 1,2, 5, 6 NOT USED
1 CHANNEL 1 VOICE (RJ-11 JACK)
L CHANNEL 1 LINE (BANTAM JACK)
D CHANNEL 1 DROP (BANTAM JACK)
2 CHANNEL 2 VOICE (RJ-11 JACK)
L CHANNEL 2 LINE (BANTAM JACK)
D CHANNEL 2 DROP (BANTAM JACK)
MA-303B
C
H CHANNEL 1 VOICE (REMOVABLE TERMINAL BLOCK)
1
L CHANNEL 1 LINE (BANTAM JACK)
D CHANNEL 1 DROP (BANTAM JACK)
C
H CHANNEL 2 VOICE (REMOVABLE TERMINAL BLOCK)
2
L CHANNEL 2 LINE (BANTAM JACK)
D CHANNEL 2 DROP (BANTAM JACK)
TIP
RING
