Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
RFL VF-16B RFL Electronics Inc.
January 17, 2007 14 (973)
334-3100
Table 1. continued - Controls and indicators, RFL VF-16B module
Item Name/Description Function
11 DIP Switch SW8 SW8-1 to SW8-6 Sets Channel 2 Rx level (Table 3)
SW8-7 and SW8-8 Spare
12 DIP Switch SW9
SW9-1 and SW9-2 Channel 2 Ring Voltage (Table 4) See Note B belo
w
SW9-3 C
hannel 2 Ring DC Offset See Note B below
ON: enables DC offset (Table 4)
OFF: disables DC offset
SW9-4 Channel 2 Automatic Ring Down
ON: enables ARD
OFF: disables ARD
SW9-5 Channel 2 Loop Current
ON: Loop current = 41 mA
OFF: Loop current = 20 mA
SW9-6 and SW9-7 Channel 2 Ring Delay (Table 5)
SW9-8 Spare
13
DIP Switch SW10 SW10-1 and SW10-2 Loopback Mode (Table 6)
SW10-3 Selects Local or Remote mode
UP: Local mode
DOWN: Remote mode
SW10-4 Turns module service ON or OFF
UP: Service is ON
DOWN: Service is OFF
14
J1 U3 programming header (for factory use only)
15
J2 For factory use only (not included)
16
J3 U9 programming header (for factory use only)
17
J4 Channel 1 drop/line
18
J5 Channel 2 drop/line
19
Test point 1 Ground
20
Test point 2 +5V
21
Test point 3
+3.3V
22
Test point 4
+2.5V
23
Test point 5
+15V
24
Test point 6
+VPIC
25
Test point 7
For factory use only
26
Test point 8
For factory use only
27
Test point 9
Tip 2
28
Test point 10
Ring 2
29
Test point 11
CH1 VBAT
30
Test point 12
Tip 1
31
Test point 13
Ring 1
32
Test point 14
CH2 VBAT
Note A - If a self diagnosed line fault is detected on Channel 1, the tip-ring lines of Channel 1 will enter a high
impedance state and all three Channel 1 (DS1) LEDs (off-hook[red], ringing [yellow], and CH enable [green] ) will
illuminate. NMS will also report off-hook and ringing for Channel 1. To exit this state, power must be cycled off and
on for the board, or the channel must be disabled and then enabled, or the service to the card must be switched off
and then on. The same line fault detection feature is present on Channel 2 (LEDs, DS2).
Note
B – When using module adapter MA-302 or MA-302A always set to the factory default.
