Table 8. continued - Remote configuration settings (“P” codes)
P Code Digit(s) And Switch Equivalent Value
(1)
Description
P09
B 0 0 0 0 0 0 0 0
↑ ↑ - - - - - -
00 Partial Analog mode
LOOPBACK MODE
01 Full Analog mode
10 Digital mode
11 Dual Analog mode
B 0 0 0 0 0 0 0 0
- - ↑ ↑ ↑ ↑ ↑ ↑
… For future use
P10
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
… For factory use only. Should read back as:
Firmware revision.
DO NOT WRITE TO THIS BYTE
P11
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
… For factory use only. Should read back as: 0
DO NOT WRITE TO THIS BYTE
P12
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
… For factory use only. Should read back as: 1
DO NOT WRITE TO THIS BYTE
