Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
RFL VF-16B RFL Electronics Inc.
January 17, 2007 34 (973) 334-3100
“S” CODES
“S” codes appear in response to a “STATUS?” query. There are four “S” codes for the RFL VF-16B,
S1 through S4. Like the “P” codes, this number is displayed in both decimal and binary form. Table 9
describes the meanings of the “S” codes for the VF-16B.
A typical response to a “STATUS?” query looks like this:
* OK
CHANNEL CARD 3, TYPE 182
S01 = 3 (B00000011)
S02 = 3 (B00000011)
S03 = 0 (B00000000)
S04 = 1 (B00000001);
Table 9. Remote status messages (“S” codes)
S Code Digit(s) And Switch Equivalent Value
(1)
Description
S1
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
0 Ch2 Config Valid
CH2 CONFIG INVALID
1 Ch2 Config Invalid
B 0 0 0 0 0 0 0 0
- ↑ - - - - - -
0 Ch2 Disabled
CH2 ENABLED
1 Ch2 Enabled
B 0 0 0 0 0 0 0 0
- - ↑ - - - - -
0 Ch2 Not Ringing
CH2 RINGING
1 Ch2 Ringing
B 0 0 0 0 0 0 0 0
- - - ↑ - - - -
0 Ch2 Not Offhook
CH2 OFFHOOK
1 Ch2 Offhook
B 0 0 0 0 0 0 0 0
- - - - ↑ - - -
0 Ch1 Config Valid
CH1 CFG INVALID
1 Ch1 Config Invalid
B 0 0 0 0 0 0 0 0
- - - - - ↑ - -
0
Ch1 Disabled
CH1 ENABLED
1 Ch1 Enabled
B 0 0 0 0 0 0 0 0
- - - - - - - ↑ -
0 C
h1 Not Ringing
CH1 RINGING
1 Ch1 Ringing
B 0 0 0 0 0 0 0 0
- - - - - - - ↑
0 Ch1 Not Offhook
CH1 OFFHOOK
1 Ch1 Offhook
>> table continues on next page <<
