ALARM RELAY SPECIFICATIONS
Maximum continuous current 1 A (inductive)
Maximum breaking current 1 A (resistive)
Maximum open circuit voltage 280 Vdc
Maximum operate time 10 ms
SYSTEM PERFORMANCE
Operate time (back to back) 3 ms (solid state)
Dependability (IMUX 2000 in frame) 99.99%
Security (10
-3
BER on IMUX 2000) 1X10
-22
SYSTEM COMPATIBILITY
The RFL DS-TT is compatible with all RFL 9001 and IMUX 2000 T1/E1 multiplexers
(See note on page 1)
OPERATING MODES
Full duplex (transmit and receive)
POWER CONSUMPTION
2.0 watts maximum
DIMENSIONS
Transfer Trip Module
2 Function I/O
Adapter Module
4 Function I/O
Adapter Module
Length: 9.8 in (24.8 cm) 4.7 in (11.9 cm) 4.7 in (11.9 cm)
Width: 0.6 in (1.5 cm) 2.1 in (5.3 cm) 4.2 in (10.6 cm)
Height: 4.5 in (11.4 cm) 5.0 in (12.7 cm) 5.0 in (12.7 cm)
WEIGHT
Transfer Trip Module
2 Function I/O
Adapter Module
4 Function I/O
Adapter Module
Net: 0.62 lb (0.28 kg) 0.70 lb (0.32 kg) 1.22 lb (0.55 kg)
Shipping: 1 lb (0.45 kg) 1 lb (0.45 kg) 1.5 lb (0.68 kg)
