Table 4. Remote Configuration Settings
P Code Bits Used Value Description
SRVC
(6)
... ON Turns service on (module enabled)
OFF Turns service off (module disabled)
P01
(1)
B 0 0 0 0 0 0 0 0
3 - 256 (ms)
(Set
ting = 2 to 255)
Function 1 trip hold timer
P02
(1)
B 0 0 0 0 0 0 0 0
3 - 256 (ms)
(Set
ting = 2 to 255)
Function 2 trip hold timer
P03
(1)
B 0 0 0 0 0 0 0 0
3 - 256 (ms)
(Set
ting = 2 to 255)
Function 3 trip hold timer
P04
(1)
B 0 0 0 0 0 0 0 0
3 - 256 (ms)
(Set
ting = 2 to 255)
Function 4 trip hold timer
P05
(2)
B 0 0 0 0 0 0 0 0
3 - 16 (ms)
(Set
ting = 2 to 15)
Function 1 pretrip timer
B 0 0 0 0 0 0 0 0
3 - 16 (ms)
(Set
ting = 2 to 15)
Function 2 pretrip timer
P06
(2)
B 0 0 0 0 0 0 0 0
3 - 16 (ms)
(Set
ting = 2 to 15)
Function 3 pretrip timer
B 0 0 0 0 0 0 0 0
3 - 16 (ms)
(Set
ting = 2 to 15)
Function 4 pretrip timer
P07 B 0 0 0 0 0 0 0 0
...
0
Functi
on 1 output polarity in normal mode or
start input polarity in DCB mode.
norma
l
1 invert
B 0 0 0 0 0 0 0 0
...
0
Functi
on 2 output polarity in normal mode or
stop input polarity in DCB mode.
norma
l
1 invert
B 0 0 0 0 0 0 0 0
...
0
Function 3 output polarity
norma
l
1 invert
B 0 0 0 0 0 0 0 0
...
0
Function 4 output polarity
norma
l
1 invert
See notes on pages 19 t
hrough 24.
