INSTALLATION
Before the Status Module can be placed in service, it must be installed in a multiplexer shelf.
Installation involves determining the module slot in the Main Shelf or Expansion Shelf where the
Status Module will be installed, inserting a Module Adapter into the rear of the shelf behind the Status
Module slot, connecting all signal wiring to the Module Adapter, checking the settings of all switches
and jumpers, and inserting the Status Module into the front of the shelf.
NOTE
Power supply and time slot considerations may affect the installation of the Status Module
into an existing multiplexer shelf. Refer to the portions of your multiplexer operation manual
covering “Channel Module Configuration Guidelines” and “Adding More Channel Modules
To Existing Systems” for more information.
The following instructions are provided for installing the Status Module into existing systems. If
the module was included as part of a system, installation was done at the factory, otherwise,
proceed as follows:
1. Carefully inspect the Status Module and its Module Adapter for shipping damage.
If you suspect damage to the Status Module or its Module Adapter, immediately
contact RFL’s Customer Service Department at the number shown at the bottom of
this page.
2. Determine which module slot in the Main Shelf or Expansion Shelf the Status Module will
be installed in.
The Status Module occupies one module slot in the Main Shelf or Expansion Shelf.
Refer to the “as supplied” drawings furnished with the equipment for more
information.
3. Determine which Module Adapter will be used to make connections to the Status Module.
Each Status Module installed in an IMUX 2000 multiplexer requires a Module
Adapter. The Module Adapter provides the appropriate connections for the
desired interface.
There are six different Module Adapters that can be used with the Status Module:
Module
Adapter
Part Number Input/Output Type Figures
MA-601
MA-602
MA-603
MA-604
MA-605
MA-606
106140-1
106140-2
106140-3
106140-4
106140-5
106140-6
8 Input module
8 Output module
16 Input module
16 Output module
8 Output/8 Input (points 0-7 are outputs, 8-15 are inputs)
8 Input/8 Output (points 0-7 are inputs, 8-15 are outputs)
2&4
2&4
3&4
3&4
3&4
3&4
RFL Status Module RFL Electronics Inc.
July 15, 2007 3 (973) 334-3100
