Table 3. Remote Configuration Settings (“P” codes)
P Code Bits Used Value Description
P01
(1)
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑
T1: 1 to 24
E1: 1 to 31
Rx timeslot
B 0 0 0 0 0 0 0 0 0 Receive from A direction
↑ 1 Receive from B direction
P02
(2)
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑
T1: 1 to 24
E1: 1 to 31
Tx timeslot
P03
(3)
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑
0 to 63 Rx address
P04
(3)
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑
0 to 63 Tx address
P05 B 0 0 0 0 0 0 0 0 0 Scan speed = 10ms
↑ 1 Scan speed = 100ms
B 0 0 0 0 0 0 0 0 0 I/O 8-15 type = output
↑ 1 I/O 8-15 type = input
B 0 0 0 0 0 0 0 0 0 I/O 0-7 type = output
↑ 1 I/O 0-7 type = input
B 0 0 0 0 0 0 0 0 0 System type = T1
↑ 1 System type = E1
P06
B 0 0 0 0 0 0 0 0
0 Output polarity of 0-7 = normal
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ 1 Output polarity of 0-7 = inverted
P07 B 0 0 0 0 0 0 0 0 0 Output polarity of 8-15 = normal
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ 1 Output polarity of 8-15 = inverted
>> See next page for notes <<
