Table 13. Remote configuration settings (“P” codes) for RFL TMX module
P Code Digit(s) And Switch Equivalent Value * Description
P1 B 0 0 0 0 0 0 0 0
- - - ↑ ↑ ↑ ↑ ↑
TIME SLOT SELECT
00001 to 11000
T1 Settings
With LSB on the right, these five bits represent the
binary value of the desired time slot between 1 and
24 in a T1 network. See Table 7 for a complete list
of these values.
00001 to 11111
E1 Settings
With LSB on the right, these five bits represent the
binary value of the desired time slot between 1 and
31 in an E1 network. See Table 7 for a complete list
of these values.
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ - - - - -
SPARE
. . . Not used.
P2 B 0 0 0 0 0 0 0 0
- - ↑ ↑ ↑ ↑ ↑ ↑
TRANSMITTER ADDRESS
000000 to
111111
See Table 8
(TMX address is embedded in transmitted data stream)
B 0 0 0 0 0 0 0 0
- ↑ - - - - - -
SPARE
. . . Not used.
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
TERMINAL/DIA or DIB
0 DIB
1 Terminal/DIA
P3 B 0 0 0 0 0 0 0 0 000 Live data on all analog channels
- - - - - ↑ ↑ ↑ 001 Calibration data on analog channel 1 only
CALIBRATOR SELECT 010 Calibration data on analog channel 2 only
011 Calibration data on analog channel 3 only
100 Calibration data on analog channel 4 only
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ - - -
SPARE
. . . Not used.
P4 B 0 0 0 0 0 0 0 0 000 Input gain = 1
- - - - - ↑ ↑ ↑ 001 Input gain = 2
ANALOG CHANNEL 1 010 Input gain = 4
INPUT GAIN SELECT 011 Input gain = 8
B 0 0 0 0 0 0 0 0 0 Positive polarity
- - - - ↑ - - -
ANALOG CHANNEL 1
OFFSET POLARITY
1 Negative pol
ari
ty
B 0 0 0 0 0 0 0 0 000 Input gain = 1
- ↑ ↑ ↑ - - - - 001 Input gain = 2
ANALOG CHANNEL 2 010 Input gain = 4
INPUT GAIN SELECT 011 Input gain = 8
B 0 0 0 0 0 0 0 0 0 Positive polarity
↑ - - - - - - -
ANALOG CHANNEL 2
OFFSET POLARITY
1 Negative pol
ari
ty
