Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
RFL TMX/TMR RFL Electronics Inc.
January 25, 2012 29 (973) 334-3100
Table 13. continued - Remote configuration settings (“P” codes) for RFL TMX module
P Code Digit(s) And Switch Equivalent
Value * Description
P5
B 0 0 0 0 0 0 0 0
000 Input gain = 1
- - - - - ↑ ↑ ↑
001 Input gain = 2
ANALOG CHANNEL 3
010 Input gain = 4
INPUT GAIN SELECT
011 Input gain = 8
B 0 0 0 0 0 0 0 0
0 Positive polarity
- - - - ↑ - - -
ANALOG CHANNEL 3
OFFSET POLARITY
1 Negative pol
ari
ty
B 0 0 0 0 0 0 0 0
000 Input gain = 1
- ↑ ↑ ↑ - - - -
001 Input gain = 2
ANALOG CHANNEL 4
010 Input gain = 4
INPUT GAIN SELECT
011 Input gain = 8
B 0 0 0 0 0 0 0 0
0 Positive polarity
↑ - - - - - - -
ANALOG CHANNEL 4
OFFSET POLARITY
1 Negative pol
ari
ty
P6
B 0 0 0 0 0 0 0 0
- - - - - ↑ ↑ ↑
ANALOG CHANNEL 1
FIXED DATA LEVEL
SELECTOR
000 to 111 See table 14
B 0 0 0 0 0 0 0 0
0 Connects analog channel 1 to live data
- - - - ↑ - - -
ANALOG CHANNEL 1
FIXED LEVEL SWITCH
1 Forces analog channel 1 data to fixed level
at A/D converter.
B 0 0 0 0 0 0 0 0
- ↑ ↑ ↑ - - - -
ANALOG CHANNEL 2
FIXED DATA LEVEL
SELECTOR
000 to 111 See table 14
B 0 0 0 0 0 0 0 0 0 Connects analog channel 2 to live data
↑ - - - - - - -
ANALOG CHANNEL 2
FIXED LEVEL SWITCH
1 Forces analog channel 2 data to fixed level
at A/D converter.
P7
B 0 0 0 0 0 0 0 0
- - - - - ↑ ↑ ↑
ANALOG CHANNEL 3
FIXED DATA LEVEL
SELECTOR
000 to 111 See table 14
B 0 0 0 0 0 0 0 0
0 Connects analog channel 3 to live data
- - - - ↑ - - -
ANALOG CHANNEL 3
FIXED LEVEL SWITCH
1 Forces analog channel 3 data to fixed level
at A/D converter.
B 0 0 0 0 0 0 0 0
- ↑ ↑ ↑ - - - -
ANALOG CHANNEL 4 FIXED
DATA LEVEL SELECTOR
000 to 111 See table 14
B 0 0 0 0 0 0 0 0 0 Connects analog channel 4 to live data
↑ - - - - - - -
ANALOG CHANNEL 4
FIXED LEVEL SWITCH
1 Forces analog channel 4 data to fixed level
at A/D converter.
