Table 13. continued - Remote configuration settings (“P” codes) for RFL TMX module
P Code Digit(s) And Switch Equivalent Value
(1, 2)
Description
P8
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
ANALOG CHANNEL 1 OFFSET
MAGNITUDE AFTER GAIN
00000000 to
11111111
(0 decimal to
255 decimal)
See Table 15
P9
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
ANALOG CHANNEL 2 OFFSET
MAGNITUDE AFTER GAIN
00000000 to
11111111
(0 decimal to
255 decimal)
See Table 15
P10
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
ANALOG CHANNEL 3 OFFSET
MAGNITUDE AFTER GAIN
00000000 to
11111111
(0 decimal to
255 decimal)
See Table 15
P11
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
ANALOG CHANNEL 1 OFFSET
MAGNITUDE AFTER GAIN
00000000 to
11111111
(0 decimal to
255 decimal)
See Table 15
1. These are the only legal values for setting the parameters. Sett
ing any parameter to a value outside its specified range
will produce an unpredictable result.
2. When the module is switched to local mode, the values of P-Codes P8 through P11 are set to zero.
Table 14. TMX Fixed selector parameter values for analog channels 1, 2, 3 and 4
Fixed selector in
REMOTE mode
000 001 010 011 100 101 110 111
Fixed selector in
LOCAL mode
DIP=1
*
% bipolar
of
-10V to +10V
-100% -80% -50% 0 +16% +50% +80% +100%
Equivalent input
at gain=1
in Volts
-10V -8V -5V 0V +1.6V +5V +8V +10V
* This is the only selection available in local mode. It is set using DIP switch SW4-8 for analog channel 1, SW4-7 for
analog channel 2, SW4-6 for analog channel 3, and SW4-5 for analog channel 4 (See Table 2).
