RFL TMX/TMR RFL Electronics Inc.
January 25, 2012 32 (973) 334-3100
Table 17. Remote configuration settings (“P” codes) for RFL TMR module
P Code Digit(s) And Switch
Equivalent
Value
(1)
Description
P1 B 0 0 0 0 0 0 0 0
- - -
TIME SLOT SELECT
00001 to 11000
T1 Settings
With LSB on the right, these five bits represent the
binary value of the desired time slot between 1 and
24 in a T1 network. See Table 7 for a complete list
of these values.
00001 to 11111
E1 Settings
With LSB on the right, these five bits represent the
binary value of the desired time slot between 1 and
31 in an E1 network. See Table 7 for a complete list
of these values.
B 0 0 0 0 0 0 0 0
- - - - -
SPARE
. . . Not used.
P2 B 0 0 0 0 0 0 0 0
- -
TRANSMITTER ADDRESS
000000 to
111111
See Table 8
(000000 = address test disabled) TMR address to be
compared to address embedded in received data stream.
B 0 0 0 0 0 0 0 0
- - - - - - -
SPARE
. . . Not used.
B 0 0 0 0 0 0 0 0
- - - - - - -
TERMINAL/DIA or DIB
0 DIB
1 Terminal/DIA
1. These are the only legal values for setting the parameters. Setting any parameter to a value outside its
specified range will produce an unpredictable result.
