Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
RFL TMX/TMR RFL Electronics Inc.
January 25, 2012 37 (973)
334-3100
Table 18. TMR Fixed selector parameter values for analog channels 1, 2, 3 and 4
Fixed selector in
REMOTE mode
000 001 010 011 100 101 110 111
Fixed selector in
LOCAL mode
DIP=0
*
DIP=1
*
% bipolar
of
-50 mA to +50 mA
-100% -80% -50% 0 +16% +50% +80% +100%
Equivalent output
at gain=1
in mA
-50 mA -40 mA -25 mA 0 mA +8 mA +25 mA +40 mA +50 mA
* These are th
e only selections available in local mode, and are set using DIP switch SW4-6 for analog channel 1, SW5-6
for analog channel 2, SW6-6 for analog channel 3, and SW7-6 for analog channel 4 (See Table 10).
Table 19. TMR loss of signal parameter values
LOS Remote 00 01 10 11
LOS Local DIP=0 * DIP=1 *
% bipolar
of
-50 mA to +50 mA
Previous value -100% 0% +100%
Equivalent output
at gain=1
in mA
Previous value -50 mA 0 mA +50 mA
* These are th
e only selections available in local mode, and are set using DIP switch SW4-4 for analog channel 1, SW5-4
for analog channel 2, SW6-4 for analog channel 3, and SW7-4 for analog channel 4 (See Table 10).
