“S” CODES
“S” codes appear in response to a “STATUS?” query. There are nine “S” codes for the RFL TMX
module: S1 through S9, and five “S” codes for the RFL TMR module: S1 through S5. Like the “P”
codes, these numbers are displayed in both decimal and binary form.
A typical TMX response to a “STATUS?” query looks like this:
* OK
CHANNEL CARD 3, TYPE 123
S01 = 3 (B00000011);
Table 21. Remote status messages (“S” codes) for the RFL TMX module
S Code Position Value Description
S1 B 0 0 0 0 0 0 0 0
- - - - - - - ↑
0 T1 is detected
T1/E1
AUTO DETECT
1 E1 is detected
B 0 0 0 0 0 0 0 0
- - - - - - ↑ -
0 SCB
configuration errors not detected
SCB
CONFIGURATION
1 SCB configuration errors detected
S2 B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
ANALOG CHANNEL 1
LSB
1111 1111 1111 1111
to
LS by
te of analog channel 1 data
in signed magnitude format
MSB LSB
S3
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
ANALOG CHANNEL 1
MSB
0111 1111 1111 1111
MS
byte of analog channel 1 data
in signed magnitude format
M
B L
B
SIGN BIT
RFL TMX/TMR RFL Electronics Inc.
January 25, 2012 39 (973)
334-3100
