Table 6. Remote configuration settings (“P” codes)
P Code Digit(s) And Switch Equivalent Value
(1)
Description
P01
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
0 Bus A Disabled
BUS A SETTING
1 Bus A Enabled
B 0 0 0 0 0 0 0 0
- ↑ - - - - - -
0
Bus B Disabled
BUS B SETTING
1 Bus B Enabled
B 0 0 0 0 0 0 0 0
- - ↑ - - - - -
0 CAS Disabled for E1 MUX
CAS SETTING
(E1 MUX ONLY)
1 CAS Enabl
ed for E1 MUX
B 0 0 0 0 0 0 0 0
- - - ↑ ↑ ↑ ↑ ↑
TIMESLOT SELECTION
T1
/E1
00001 to 11000
T1 Settin
gs
From left to right, these five bits represent the binary
value of the desired time slot between 1 through 24
in a T1 network. See Table 4 for a complete list of
these values.
00001 to 11111
E1 Settin
gs
From left to right, these five bits represent the binary
value of the desired time slot between 1 through 31
in an E1 network. See Table 4 for a complete list of
these values.
P02
B 0 0 0 0 0 0 0 0
- - - - ↑ ↑ ↑ ↑
From 0000 (0)
to 1001 (9)
BCD Number (0 to 9)
Local CM Address, Hundreds Position
LOCAL CM ADDRESS
(HUNDREDS POSITION)
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ - - - -
… Not used
P03
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ - - - -
From 0000 (0)
to 1001 (9)
BCD Number (0 to 9)
Local CM Address, Tens Position
LOCAL CM ADDRESS
(TENS POSITION)
B 0 0 0 0 0 0 0 0
- - - - ↑ ↑ ↑ ↑
From 0000 (0)
t
o 1001 (9)
BCD Number (0 to 9)
Local CM Address, Units Position
LOCAL CM ADDRESS
(UNITS POSITION)
>> ta
ble continues on next page <<
1. These are the only legal values for setting parameters. Setting a parameter to a value outside its specified
range will produce unpredictable results.
