Table 6. continued - Remote configuration settings (“P” codes)
P Code Digit(s) And Switch Equivalent Value
(1)
Description
P04
B 0 0 0 0 0 0 0 0
00 Disable Loopbacks
↑ ↑ - - - - - -
01 Enable Ports 1 & 2 Equipment Loopbacks
PORT LOOPBACK SETTINGS
10 Enable Port 1 Payload Loopback
11 Enable Port 2 Payload Loopback
B 0 0 0 0 0 0 0 0
- - ↑ ↑ ↑ ↑ ↑ ↑
… Not used
P05
B 0 0 0 0 0 0 0 0
000 2400
↑ ↑ ↑ - - - - -
001 4800
BAUD SETTINGS
010 9600
011 19,200
100 38,400
101 Undefined
110 Undefined
111 Undefined
B 0 0 0 0 0 0 0 0
000 None
- - - ↑ ↑ ↑ - -
001 Undefined
PARITY SETTINGS
010 Undefined
011 Undefined
100 Odd
101 Even
110 Mark
111 Space
B 0 0 0 0 0 0 0 0
00 7 Data Bits
- - - - - - ↑ ↑
01 8 Data Bits
WORD LENGTH SETTINGS
10 Undefined
11 Undefined
>> table continues on next page <<
