Table 6. continued - Remote configuration settings (“P” codes)
P Code Digit(s) And Switch Equivalent Value
(1)
Description
P06
B 0 0 0 0 0 0 0 0
00 Any CM Address
↑ ↑ - - - - - -
01 Equal To
CM ADDRESS PASS SETTINGS
10 Equal To Or Greater Than (Force FDL Search)
(NMS MODE ONLY)
11 Equal To Or Less Than (Force FDL Search)
B 0 0 0 0 0 0 0 0
000 Broadcast
- - - ↑ ↑ ↑ - -
001 NMS
APPLICATION MODE
SETTINGS
010 Master
011 D&I Slave (Bus Direction Points Towards Master)
100 End Slave (Bus Direction Points Towards Master)
101 Mode is undefined
110 Mode is undefined
111 Mode is undefined
B 0 0 0 0 0 0 0 0
0 Port 2 Disabled
- - - - - - ↑ -
PORT 2 ENABLE SETTINGS
1 Port Enabled
B 0 0 0 0 0 0 0 0
0 T1/E1 and Port Rogue Detection Disabled
- - - - - - - ↑
ROGUE SETTINGS
1 T1/E1 and Port Rogue Detection Enabled
B 0 0 0 0 0 0 0 0
… Not used
- - ↑ - - - - -
P07
B 0 0 0 0 0 0 0 0
… Not used
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
P08
B 0 0 0 0 0 0 0 0
… Not used
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
P09
B 0 0 0 0 0 0 0 0
… Not used
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
P10
B 0 0 0 0 0 0 0 0
… Not used
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
