Table 7. continued - Remote status messages (“S” codes)
S Code Digit(s) And Switch Equivalent Value
(1)
Description
S02
B 0 0 0 0 0 0 0 0
xxx00 Both Busses Disabled – Mode Undefined
- - - ↑ ↑ ↑ ↑ ↑
00001 Term/
DI-A Broadcast Mode
APPLICATION CONFIGURATION STATUS
00010 DI-B B
roadcast Mode
00011 D&I Broadcast Mode
00101 Term/DI-A NMS Mode
00110 DI-B NMS Mode
00111 D&I NMS Mode
01001 Term/DI-A Master
01010 DI-B Master
01011 D&I Master
01101 D&I Slave - Master is in direction A
01110 D&I Slave - Master is in direction B
10001 End Slave - Master is in direction A
10010 Slave End - Master is in direction B
10011 Mode is undefined
01111 Mode is undefined
101xx Mode is undefined
11xxx Mode is undefined
CM ADDRESSING SUPPORT
000xx CM
Addressing Not Supported
010xx CM Addressing Not Supported
011xx CM Addressing Not Supported
001xx CM Addressing Is Supported
PORT 1 APPLICATION STATUS
000xx Port 1 i
s Broadcast Port
001xx Port 1 is Local User Port (Use RS-232 Only)
010xx Port 1 is Master Port
011xx Port 1 is a Slave Port
100xx Port 1 is a Slave Port
101xx Port 1 is Undefined
11xxx Port 1 is Undefined
PORT 2 APPLICATION STATUS
000xx Port 2 i
s Broadcast Port (If Available)
001xx Port 2 is CM Port (Use RS-232 Only)
010xx Port 2 is Slave of Port 1 Master (If Available)
011xx Port 2 is a Slave Port (If Available)
100xx Port 2 is a Slave Port (If Available)
101xx Port 2 is Undefined
11xxx Port 2 is Undefined
B 0 0 0 0 0 0 0 0
… Not used
↑ ↑ ↑ - - - - -
>> ta
ble continues on next page <<
