Table 7. continued - Remote status messages (“S” codes)
S Code Digit(s) And Switch Equivalent Value
(1)
Description
S08
B 0 0 0 0 0 0 0 0
xxxx0 Port 1 Output Idle
- - - ↑ ↑ ↑ ↑ ↑
xxxx1 Port 1 Output Active
PORT 1 INPUT/OUTPUT STATUS
xxx0x Port 1 Output Data Status - No Errors
xxx1x Port 1 Output Data Status - Errors
xx0xx Port 1 Input Idle
xx1xx Port 1 Input Active
x0xxx Port 1 Input Rogue Control Not Active
x1xxx Port 1 Input Rogue Control Active
0xxxx Port 1 Input Data Status - No Errors
1xxxx Port 1 Input Data Status - Errors
B 0 0 0 0 0 0 0 0
… Not used
↑ ↑ ↑ - - - - -
S09
B 0 0 0 0 0 0 0 0
xxxx0 Port 2 Output Idle
- - - ↑ ↑ ↑ ↑ ↑
xxxx1 Port 2 Output Active
PORT 2 INPUT/OUTPUT STATUS
xxx0x Port 2 Output Data Status - No Errors
xxx1x Port 2 Output Data Status - Errors
xx0xx Port 2 Input Idle
xx1xx Port 2 Input Active
x0xxx Port 2 Input Rogue Control Not Active
x1xxx Port 2 Input Rogue Control Active
0xxxx Port 2 Input Data Status - No Errors
1xxxx Port 2 Input Data Status - Errors
B 0 0 0 0 0 0 0 0
… Not used
↑ ↑ ↑ - - - - -
>> table continues on next page <<
