Table 7
. continued - Remote status messages (“S” codes)
S Code Digit(s) And Switch Equivalent Value
(1)
Description
S10
B 0 0 0 0 0 0 0 0
xxxx0 TXA Data Path Idle
- - - ↑ ↑ ↑ ↑ ↑
xxxx1 TXA Data
Path Active
TXA/RX
B STATUS FOR T1/E1
xx0xx RXB Data Path Idle
xx1xx RXB Data Path Active
x0xxx RXB Rogue Control Not Active
x1xxx RXB Rogue Control Active
0xxxx RXB Data Status – No Errors
1xxxx RXB Data Status - Errors
B 0 0 0 0 0 0 0 0
… Not used
↑ ↑ ↑ - - - - -
S11
B 0 0 0 0 0 0 0 0
xxxx0 TXB Data Path Idle
- - - ↑ ↑ ↑ ↑ ↑
xxxx1 TXB Dat
a Path Active
TXB/RX
A STATUS FOR T1/E1
xx0xx RXA Data Path Idle
xx1xx RXA Data Path Active
x0xxx RXA Rogue Control Not Active
x1xxx RXA Rogue Control Active
0xxxx RXA Data Status – No Errors
1xxxx RXA Data Status - Errors
B 0 0 0 0 0 0 0 0
… Not used
↑ ↑ ↑ - - - - -
