Chapter 9 - SNMP Configuration and Control
SNMP Access Gateway User’s Manual - v1.0 -- 11/99 - Page 34
sensorAlarmCounter This read-only object holds the number of seconds
that the sensor alarm has been in its active
state. For a contact closure input this counter
is the number of seconds that the contact closure
has been sensed in the (opened or closed) active
state. For an analog sensor this counter is the
number of seconds that the sensor has been in the
(overmax, undermin, outsiderange) active state.
sensorAlarmThreshold This object holds the number of seconds that the
sensor alarm must be in the active state to
trigger the sensor alarm actions.
sensorAlarmAcked This object, when set to any value, acknowledges
the active state of this sensor alarm, and stops
the repeating of any traps or pager actions, and
turns off the buzzer if the buzzer activation is
based on the active state of this sensor.
sensorlarmBeeperActions This object indicates the buzzer (audible alarm)
actions associated with this sensor alarm. The
object value may be may be 0 - no action, 1 - beep
once every 10 seconds or 2 - beep continuously.
sensorAlarmPagerActions This object shows which pagers are to be paged
when the actions associated with this sensor alarm
are activated. Each bit in this integer is
assigned to one of the pagers 1-8. Bit 0 (value
of 1) is assigned to pager 1, bit 1 (value of 2)
is assigned to pager 2, etc. If a bit in the
sensorAlarmPagerActions integer is cleared, then
that pager is not activated by this sensor alarm.
If a bit in the sensorAlarmPagerActions is set,
then that pager is activated by this sensor alarm.
sensorAlarmTrapActions This object shows which SNMP managers are sent
traps when the actions associated with this sensor
alarm are activated. Each bit in this integer is
assigned to one of the SNMP managers 1-8. Bit 0
(value of 1) is assigned to SNMP manager 1, bit 1
(value of 2) is assigned to SNMP manager 2, etc.
If a bit in the sensorAlarmTrapActions integer is
cleared, then that SNMP manager is not sent a trap
based on this sensor alarm. If a bit in the
sensorAlarmTrapActions is set, then that SNMP
manager is sent a trap based on this sensor alarm.
9.8 - actions
actionsBuzzerState This object holds the current operating state of
the buzzer. Values for this object may be 0 - no
buzzer action, 1 - buzzer active one second out of
each 10 seconds, 2 - buzzer on continuously.
actionsPagerTable This table holds the settings for the 8 pagers.
Each pager may have a different phone number,
pagerID, etc., so that a combination of pagers may
be used to manage the alarms generated by the SNMP
Access Gateway.
pagerType The pager may be either an alphanumeric pager, or
a numeric pager. If the pager is numeric, this
object should be set to a value of 0, if the pager
is alphanumeric this object should be set to a
value of 1.
pagerPhonenumber This text string is the phone number what is
dialed to reach the paging service.
sensor pagerID When the pager is alphanumeric, the pagerID is a
text string which must match the pager ID as
assigned by the pager company. When the pager is
a numeric pager, the pagerID is the second number
sequence which is sent, to activate the page.
