App Note C: IMUX TRAP Messages
C.2 Trap Codes
The table provided below lists all of the possible traps from the system.. Alarm numbering begins
at 100 and is structured as follows:
NO. SOURCE DESCRIPTION O/VIEW VARBIND
STATUS Variable Value Range
101 Interface ALERT AT CHANNEL CARD # CRITICAL Channel # 1-36, 40, 41, 43
102 Interface Reset ALERT AT CHANNEL CARD
#
CRITICAL Channel # 1-36, 40, 41, 43
103 Interfaces ALERT AT MULTIPLE CARDS CRITICAL # of Cards 2-36
104 Interfaces Reset ALERT AT MULTIPLE
CARDS
CRITICAL # of Cards 2-36
105 CM-4 Redundant power supply failure CRITICAL n/a
106 CM-4 Reset Redundant power supply failure CRITICAL n/a
107 CM-4 Shelf status (alert) CRITICAL n/a
108 CM-4 Reset Shelf status (alert) CRITICAL n/a
109 CM-4 Shelf status (alarm) CRITICAL n/a
110 CM-4 Reset Shelf status (alarm) CRITICAL n/a
111 CM-4 D&I-B Configuration alarm CRITICAL n/a
112 CM-4 Reset D&I-B Configuration alarm CRITICAL n/a
113 CM-4 XMIT timing not correct CRITICAL n/a
114 CM-4 Reset XMIT timing not correct CRITICAL n/a
115 CM-4 RCV carrier loss CRITICAL n/a
116 CM-4 Reset RCV carrier loss CRITICAL n/a
117 CM-4 Excess receive jitter CRITICAL n/a
118 CM-4 Reset Excess receive jitter CRITICAL n/a
119 CM-4 RCV out of frame CRITICAL n/a
120 CM-4 Reset RCV out of frame CRITICAL n/a
121 CM-4 Other side (DI-A) out of frame CRITICAL n/a
122 CM-4 Reset Other side (DI-A) out of frame CRITICAL n/a
123 CM-4 Other side (DI-B) out of frame CRITICAL n/a
124 CM-4 Reset Other side (DI-B) out of frame CRITICAL n/a
125 CM-4 RCV all ones CRITICAL n/a
126 CM-4 Reset RCV all ones CRITICAL n/a
127 CM-4 RCV remote alarm CRITICAL n/a
128 CM-4 Reset RCV remote alarm CRITICAL n/a
129 CM-4 XMIT clock free-running CRITICAL n/a
130 CM-4 Reset XMIT clock free-running CRITICAL n/a
131 CM-4 XMIT using fallback timing CRITICAL n/a
132 CM-4 Reset XMIT using fallback timing CRITICAL n/a
2000 CM-4 Power Up NORMAL 0
2005 Interfaces Clear All Alarms for Subaddress NORMAL Subaddress 1-43
August 4, 2009
53
