App Note C: IMUX TRAP Messages
App Note C: IMUX TRAP messages
C.1 Trap Format
The gateway has been designed to work specifically with all versions of CM-4 software. RS232 trap
messages are created
by the IMUX and sent to the SAG. This allows the gateway to generate SNMP traps
as a result of a message from the IMUX. These traps will contain data that defines the fault condition on
the IMUX.
The trap
messages contain the following information, which is unique to the IMUX
Generic tra
p number 6
Specific tr
ap n
umber 1-9999 (from serial data string)
Enterprise ID 1.3.6.1.4.1.2743
Varbind (including)
Trap ID 1.3.6.1.4.1.2743.1.1.1.3
Community string x|y|z (from serial string, x=network(1),y=node address(1-999),
z=interface(1-99))
Message string text (from serial string)
C.2 Interface Codes
The following codes represent interfaces within the IMUX
1-36 IMUX channel cards with a matching SCB address
37 Terminal CM-4
38 D&I-A CM-4
39 D&I-B CM-4
40 Term or D&I-A standby CM-4
41 D&I-B standby CM-4
43 R-DACS or MDACS
