BIT SWITCHES
SM 23 B620
Fax Option
B620
System Switch 02 SP No. 1-101-003
No FUNCTION COMMENTS
0-1 Not used Do not change the settings.
2 Communication stall fail safe.
0: Disabled
1: Enabled
If enabled, the machine cuts communication within
one hour of a communication error but the
connection remains established.
3-4 Not used. Do not change the settings.
5 Not used Do not change the setting.
6
to
7
Memory read/write by RDS
Bit 7 6 Setting
0 0 Always disabled
0 1 User selectable
1 0 User selectable
1 1 Always enabled
(0,0): All RDS systems are always locked out.
(0,1), (1,0): Normally, RDS systems are locked out,
but the user can temporarily switch RDS on to allow
RDS operations to take place. RDS will
automatically be locked out again after a certain
time, which is stored in System Switch 03. Note that
if an RDS operation takes place, RDS will not switch
off until this time limit has expired.
(1,1): At any time, an RDS system can access the
machine.
System Switch 03 SP No. 1-101-004
No FUNCTION COMMENTS
0
to
7
Length of time that RDS is
temporarily switched on when
bits 6 and 7 of System Switch
02 are set to “User selectable”
00 - 99 hours (BCD).
This setting is only valid if bits 6 and 7 of System
Switch 02 are set to “User selectable”.
The default setting is 24 hours.
System Switch 04 SP No. 1-101-005
No FUNCTION COMMENTS
0-2 Not used Do not change the settings.
3
Printing dedicated TX
parameters on Quick Dial Lists
0: Disabled
1: Enabled
1: Each Quick dial number on the list is printed with
the dedicated TX parameters (10 bytes each).
The first 10 bytes of data are the programmed
dedicated TX parameters; 34 bytes of data are
printed (the other 24 bytes have no use for service
technicians).
4 Not used Do not change the setting.
5
Memory file transfer operation
0: User level
1: Service level
If the machine is unable to print fax messages due
to a mechanical problem, change this bit to 0 to
transfer all messages in the memory (including
confidential rx messages) to another terminal.
Always reset this bit to 1 after transfer. However,
this bit can be left at 0, if the customer’s key-
operators want to transfer the files themselves.
This machine does not support the confidential RX.
Refer to Memory File Transfer Operation Procedure
on page 29
…continued
⇒
Rev.09/2005
