U.A.11
Date Code 20090715 User’s Guide SEL-421 Relay
Firmware and Manual Versions
Instruction Manual
version number and CID file version number are the same. If downloaded to
the Ethernet card, an incompatible CID file will generate file parse errors dur-
ing processing and disable the IEC 61850 protocol.
If you perform an Ethernet card firmware upgrade that spans different file ver-
sion compatibilities, the relay may not be able to process the stored CID file.
See the Ethernet Port Firmware Upgrade Instructions in the SEL-400 Series
Firmware Upgrade Instructions for CID file conversion procedures.
See Table A.4 for compatibilities between
ACSELERATOR Architect, ICD/CID
file, and Ethernet card firmware versions.
Instruction Manual
The date code at the bottom of each page of this manual reflects the creation
or revision date.
Table A.5 lists the instruction manual release dates and a description of modi-
fications. The most recent instruction manual revisions are listed at the top.
Ta b l e A .4 ACSELERATOR Architect CID File Compatibility
ACSELERATOR Architect
Software Version
ACSELERATOR Architect
ICD/CID File Version
SEL-2702 Card
Firmware
All versions Ver 001 R100–R106
R.1.1.69.0 or higher Ver 002 (all) R107 or higher
Table A.5 Instruction Manual Revision History (Sheet 1 of 16)
Revision Date Summary of Revisions
20090715
Reference Manual
Section 2
➤ Added information about reclose cycle operations.
20090529
User’s Guide
Section 1
➤ Removed reference to 10BASE-FL communications card option.
Section 2
➤ Removed reference to 10BASE-FL communications card option.
➤ Removed Figure 2.44: Two 10BASE-FL Port Configuration, Figure 2.45: 100BASE-FX and 10BASE-FL Port
Configuration, and Figure 2.46: 10BASE-FL and 10/100BASE-T Port Configuration.
Applications Handbook
Section 7
➤ Removed reference to 10BASE-FL communications card option from Table 7.2: Ethernet Connection
Options.
20090428
User’s Guide
Appendix A
➤ Updated for firmware version R128.
