Communications Interfaces
Communications Card
Examples of GOOSE command outputs follow:
#>>GOO <Enter>
GOOSE Transmit Status
MultiCastAddr Ptag:Vlan StNum SqNum TTL Code
-----------------------------------------------------------------------------
SEL_2701_GOOSE/LLN0$GO$GooseDSet1
01-03-A7-00-00-01 2:5 1256 347 6
Data Set: SEL_2701_GOOSE/LLN2$Master
GOOSE Receive Status
MultiCastAddr Ptag:Vlan StNum SqNum TTL Code
-----------------------------------------------------------------------------
SEL-2701/LLN0$GO$GooseDSet13
01-03-A7-00-00-01 3:1 1253758689 4786543985 123456 MSG CORRUPTED
Data Set: SEL-2701-2/LLN0$Positions
GE-F60/LLN0$GO$GEGooseDSet
01-03-A7-00-00-01 3:23 12568945 34 0 TTL EXPIRED
Data Set: GE-F60/LLN1$Station1
GE-C30/LLN0$GO$GEGooseDSet
01-03-A7-00-00-01 3:343 1945 34456 456
Data Set: GE-C30/LLN2$Terminal
COOPER-EDISONPRO/LLN0$GO$CooperGooseDSet
01-03-A7-00-00-01 3:4987 45 347 123456
Data Set: COOPER-EDISONPRO/LLN2$Transmission
SEL-351-RECLOSING_DIRECTIONAL_OVERCURRENT/LLN0$GO$GooseDSet
01-03-A7-00-00-01 3:5 12568945 34783456 123456
Data Set: SEL-351-RECLOSING_DIRECTIONAL_OVERCURRENT/LLN3$Recloser
GEC_ALSTOM_123/LLN0$GO$GECGooseDSet
01-03-A7-00-00-01 3:643 12568 56 126 MSG CORRUPTED
Data Set: GEC_ALSTOM_123/LLN2$Relay
#>>
No GOOSE receive and/or GOOSE transmit subscriptions:
##>>GOO <Enter>
GOOSE Transmit Status
MultiCastAddr Ptag:Vlan StNum SqNum TTL Code
-----------------------------------------------------------------------------
No GOOSE Tx subscriptions available
GOOSE Receive Status
MultiCastAddr Ptag:Vlan StNum SqNum TTL Code
-----------------------------------------------------------------------------
No GOOSE Rx subscriptions available
##>>
GOOSE is disabled by settings (EGSE := N):
#>GOO <Enter>
GOOSE is disabled by settings. No GOOSE statistics available.
#>
Error during the processing of the IEC 61850 CID file:
#>GOO <Enter>
Error detected in the CID file parsing. All GOOSE processing disabled.
#>
