SEL-421 Relay Reference Manual Date Code 20111215
DNP3 Communications
DNP3 Documentation
Tabl e 6 . 16 SEL - 42 1 Object 12 Code Selection Operation
Indices Latch On Latch Off Pulse On Pulse Off
0–15 Set remote bits
RB1–RB16
Clear remote bits
RB1–RB16
Pulse remote bits
RB1–RB16
Clear remote bits
RB1–RB16
16–19 Pulse No action Pulse No action
20–23 Reserved Reserved Reserved Reserved
24 Pulse RB2 Pulse RB1 Pulse RB2 Pulse RB1
25 Pulse RB4 Pulse RB3 Pulse RB4 Pulse RB3
26 Pulse RB6 Pulse RB5 Pulse RB6 Pulse RB5
27 Pulse RB8 Pulse RB7 Pulse RB8 Pulse RB7
28 Pulse RB10 Pulse RB9 Pulse RB10 Pulse RB9
29 Pulse RB12 Pulse RB11 Pulse RB12 Pulse RB11
30 Pulse RB14 Pulse RB13 Pulse RB14 Pulse RB13
31 Pulse RB16 Pulse RB15 Pulse RB16 Pulse RB15
32 Pulse CC1,
Circuit Breaker 1
close bit
Pulse OC1,
Circuit Breaker 1
open bit
Pulse CC1,
Circuit Breaker 1
close bit
Pulse OC1,
Circuit Breaker 1
open bit
33 Pulse CC2,
Circuit Breaker 2
close bit
Pulse OC2,
Circuit Breaker 2
open bit
Pulse CC2,
Circuit Breaker 2
close bit
Pulse OC2,
Circuit Breaker 2
open bit
34–35 Reserved Reserved Reserved Reserved
36 Reset demands No action Reset demands No action
37 Reset demand
peaks
No action Reset demand
peaks
No action
38 Reset energy
metering
No action Reset energy
metering
No action
39 Reset breaker
monitor
No action Reset breaker
monitor
No action
40 Reset front panel
targets
No action Reset front panel
targets
No action
41 Read next relay
event
No action Read next relay
event
No action
42 Reset min/max
metering
No action Reset min/max
metering
No action
43 Reserved Reserved Reserved Reserved
44–59 Set remote bits
RB17–RB32
Clear remote bits
RB17–RB32
Pulse remote bits
RB17–RB32
Clear remote bits
RB17–RB32
60 Pulse RB18 Pulse RB17 Pulse RB18 Pulse RB17
61 Pulse RB20 Pulse RB19 Pulse RB20 Pulse RB19
62 Pulse RB22 Pulse RB21 Pulse RB22 Pulse RB21
63 Pulse RB24 Pulse RB23 Pulse RB24 Pulse RB23
64 Pulse RB26 Pulse RB25 Pulse RB26 Pulse RB25
65 Pulse RB28 Pulse RB27 Pulse RB28 Pulse RB27
66 Pulse RB30 Pulse RB29 Pulse RB30 Pulse RB29
67 Pulse RB32 Pulse RB31 Pulse RB32 Pulse RB31
