Sel SEL-421 - DNP LAN;WAN Application Example Analog Output Map

R.6.53
Date Code 20111215 Reference Manual SEL-421 Relay
DNP3 Communications
DNP LAN/WAN Application Example
AIM0011
Database Address
1:1044h Custom map position for VC angle
a
, scale by 100 and
report 2 degree change events
AIM0012
Database Address
1:METER:P (Meter
Region P)
3 500 Custom map position for three-phase real power in MW
scaled by 1000 with an event dead band of 0.5 MW
AIM0013
Database Address
1:METER:Q (Meter
Region Q)
3 500 Custom map position for three-phase real power in MW
scaled by 1000 with an event dead band of 0.5 MW
AIM0014
Database Address
1:METER:VDC1
(Meter Region 
VDC1)
DC1 voltage
a
multiplied by 100, with a dead band of 2
volts
a
Uses default scaling and dead band
Table 6.30 DNP LAN/WAN Application Example Analog Input Map (Sheet 2 of 2)
Setting Name Point
Scale
Fact or
Deadband Description
Table 6.31 DNP LAN/WAN Application Example Analog Output Map
Setting Name Setting Description
AOM0000 Database Address 0 Active Settings Group
